Scion xA I (2003-2006) heater sub 1 relay Wiring diagram
This page shows the only wiring diagram for the component.heater sub 1 relay, which is found in the car Scion xA I (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heater sub 1 relay (1 of 1)
AIR INLET CONTROL SERVO MOTOR (UNDER UPPER RIGHT SIDE OF DASH)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CONTROL CIRCUIT
ECU-IG FUSE
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT)
F/D
FOOT
FOOT MODE SWITCH
FRS
FRS REC REC/FRS
GENERATOR
GRN WIRE
GRN/WHT WIRE
HEATER SUB 1 RELAY
HOT AT ALL TIMES
HOT IN ON OR START
HTR SUB 1 FUSE
IG MAX HOT NE GND
INLET AIR POSITION DETECTION SWITCH (INSIDE SWITCH)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR 3 (LEFT SIDE OF DASH)
JUNCTION CONNECTOR 7 (RIGHT CENTER OF DASH)
JUNCTION CONNECTOR 8 (RIGHT KICK PANEL)
MAX HOT SWITCH
MAX HOT, FOOT MODE SWITCH
POSITION SWITCHES
PTC AMPLIFIER (BEHIND UPPER RIGHT SIDE OF DASH)
PTC HEATER (BEHIND LEFT SIDE OF DASH)
REC
RED WIRE
SG ALT MODE IN
WATER TEMPERATURE SENSOR (UPPER RIGHT SIDE OF DASH)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Manual a/c circuit (2 of 2) -> HEATER SUB 1 RELAY
