Front wiper/washer circuit for Scion tC II facelift (2013-2016)
Front wiper/washer circuit
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER ASSEMBLY
FRONT WASHER SWITCH
FRONT WIPER SWITCH
GRN WIRE
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEVEL WARNING SWITCH (CANADA) (RIGHT HEADLIGHT ASSEMBLY)
LT GRN WIRE
MET FUSE
MIST
MIST HI OFF LO INT INT
OFF
OFF INT
PNK WIRE
RED WIRE
WASHER FR FUSE
WASHER IND (CANADA)
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WASHER MOTOR (RIGHT FRONT OF ENGINE COMPT)
WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT)
WINDSHIELD WIPER SWITCH ASSEMBLY
WIP FR FUSE
YEL WIRE
