Trunk, tailgate, fuel door circuit for Scion tC II facelift (2013-2016)
Trunk, tailgate, fuel door circuit
BACK DOOR
BACK DOOR LOCK ASSEMBLY
BACK DOOR LOCK RELAY
BLK WIRE
BRN WIRE
BUZZER
CAN CONTROLLER
CAN I/F
CANH CANL 8 9
CERTIFICATION ECU (W/ SMART KEY SYSTEM) (RIGHT SIDE OF DASH)
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
COURTESY
D/L FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LOCK
LT GRN (OR WHT) WIRE
LT GRN WIRE
MAIN BODY ECU
MET FUSE
OPENER SWITCH ASSEMBLY
PNK WIRE
RED WIRE
RED/WHT WIRE
TAN WIRE
W/ SMART KEY SYSTEM W/O SMART KEY SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
