Power seats circuit for Scion tC II facelift (2013-2016)
Power seats circuit
1 2 3 4 LO HI
BLK WIRE
BLU WIRE
BRN WIRE
GRN WIRE
GRY WIRE
HI HI
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT FRONT SEAT CUSHION HEATER ASSEMBLY
LEFT QUARTERPANEL)
LEFT SEAT HEATER SWITCH
PNK WIRE
RED WIRE
RIGHT FRONT SEAT CUSHION HEATER ASSEMBLY
RIGHT SEAT HEATER SWITCH
S/HTR F/L FUSE
S/HTR F/R FUSE
TAN WIRE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
