Rear wiper/washer circuit for Scion tC II (2010-2013)
Rear wiper/washer circuit
BLK WIRE
BLU WIRE
GRY WIRE
HI LO OFF WASH
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
OFF WASH
ON+WASHER
ON+WASHER HI LO
REAR WASHER MOTOR (RIGHT FRONT OF ENGINE COMPT)
REAR WASHER, WIPER SWITCH
REAR WIPER MOTOR (CENTER OF REAR DOOR)
VIO WIRE
WASHER RR FUSE
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
WIP RR FUSE
YEL WIRE
