Back door opener circuit for Scion tC II (2010-2013)

Back door opener circuit

Get access

BACK DOOR LOCK ASSEMBLY BACK DOOR LOCK RELAY BACK DOOR OPENER SWITCH ASSEMBLY BLK WIRE BRN WIRE BUZZER CAN CONTROLLER CAN I/F CANH CANL 8 9 CERTIFICATION ECU (W/ SMART KEY SYSTEM) (RIGHT SIDE OF DASH) COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM COURTESY D/L FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) LOCK LT GRN WIRE MAIN BODY ECU MET FUSE ORG/ WIRE PNK WIRE RED WIRE RED/WHT WIRE W/ SMART KEY SYSTEM W/O SMART KEY SYSTEM WHT WIRE WHT/BLK WIRE YEL WIRE
