Headlights circuit, without drl for Scion tC II (2010-2013)
Headlights circuit, without drl
BEAM IND
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER ASSEMBLY
DIMMER RELAY
ECU-B FUSE
ENGINE ROOM
GRN WIRE
H-LP LH HI FUSE
H-LP LH LO FUSE
H-LP RELAY
H-LP RH HI FUSE
H-LP RH LO FUSE
H-LP- MAIN FUSE
HEAD
HEAD IND
HEADLIGHT DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT HEADLIGHT HIGH ASSEMBLY
LOW HIGH
LT GRN WIRE
ORG/ WIRE
PNK DIMMER SWITCH WIRE
PNK WIRE
R/B (LEFT SIDE OF ENGINE COMPT)
RED WIRE
RIGHT HEADLIGHT ASSEMBLY
TAIL LIGHT OFF CONTROL SWITCH
WHT WIRE
WHT/BLK WIRE
YEL WIRE
