Scion tC II (2010-2013) trg+ Wiring diagrams
This page contains all the electrical diagrams for the component. trg+, in which he is found in the car Scion tC II (2010-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram trg+ (1 of 2)
AGND
BLK WIRE
BLU WIRE
BRN WIRE
CANH CANL SWIL TXCT CODE
CERTIFICATION ECU ASSEMBLY (RIGHT SIDE OF DASH)
CLGB
COMPUTER DATA LINES SYSTEM
DATA
DOOR CONTROL RECEIVER (LEFT REAR OF PASSENGER COMPT)
ECU-B 2 FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IG CUTB
IGN FUSE
INSTRUMENT PANEL J/B (LEFT SIDE
LEFT OUTSIDE ELECTRICAL KEY ANTENNA (DRIVER'S DOOR)
LIN
LT GRN WIRE
OF DASH)
ORG/ WIRE
PNK WIRE
RCO
RDA RSSI
RED WIRE
RIGHT OUTSIDE ELECTRICAL KEY ANTENNA (PASSENGER'S DOOR)
RSSI
SENS
TRG+
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Forced entry circuit, with smart key system (4 of 4) -> TRG+
Wiring diagram trg+ (2 of 2)
AGND
BLK WIRE
BLU WIRE
BRN WIRE
CANH CANL SWIL TXCT CODE
CERTIFICATION ECU ASSEMBLY (RIGHT SIDE OF DASH)
CLGB
COMPUTER DATA LINES SYSTEM
DATA
DOOR CONTROL RECEIVER (LEFT REAR OF PASSENGER COMPT)
ECU-B 2 FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IG CUTB
IGN FUSE
INSTRUMENT PANEL J/B (LEFT SIDE
LEFT OUTSIDE ELECTRICAL KEY ANTENNA (DRIVER'S DOOR)
LIN
LT GRN WIRE
OF DASH)
ORG/ WIRE
PNK WIRE
RCO
RDA RSSI
RED WIRE
RIGHT OUTSIDE ELECTRICAL KEY ANTENNA (PASSENGER'S DOOR)
RSSI
SENS
TRG+
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power door locks circuit, with smart key system (4 of 4) -> TRG+
