Scion tC II (2010-2013) tail light off control switch Wiring diagram
This page shows the only wiring diagram for the component.tail light off control switch, which is found in the car Scion tC II (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tail light off control switch (1 of 1)
BEAM IND
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER ASSEMBLY
DIMMER RELAY
ECU-B FUSE
ENGINE ROOM
GRN WIRE
H-LP LH HI FUSE
H-LP LH LO FUSE
H-LP RELAY
H-LP RH HI FUSE
H-LP RH LO FUSE
H-LP- MAIN FUSE
HEAD
HEAD IND
HEADLIGHT DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT HEADLIGHT HIGH ASSEMBLY
LOW HIGH
LT GRN WIRE
ORG/ WIRE
PNK DIMMER SWITCH WIRE
PNK WIRE
R/B (LEFT SIDE OF ENGINE COMPT)
RED WIRE
RIGHT HEADLIGHT ASSEMBLY
TAIL LIGHT OFF CONTROL SWITCH
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Headlights circuit, without drl -> TAIL LIGHT OFF CONTROL SWITCH
