Scion tC II (2010-2013) sound mirrors systems system cooling fans system Wiring diagram
This page shows the only wiring diagram for the component.sound mirrors systems system cooling fans system, which is found in the car Scion tC II (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sound mirrors systems system cooling fans system (1 of 1)
+ECU
BACK DOOR DP-DOOR LOCK LOCK RELAY RELAY
BLK WIRE
BLU WIRE
D/L FUSE
ECU- BKUP LP FUSE ECU- HTR- IG FUSE
FROM ENGINE ROOM J/B (DIAGRAM 1 OF 2)
FROM ENGINE ROOM R/B (DIAGRAM 1 OF 2)
FROM INSTRUMENT PANEL J/B (DIAGRAM 1 OF 2)
FROM POWER SOURCE CONTROL ECU (DIAGRAM 1 OF 2)
FUSE
FUSE FUSE
GRN WIRE
GRY WIRE
IG FUSE FUSE
IGNITION/ STARTER SWITCH ASSEMBLY (W/O SMART KEY SYSTEM)
INSTRUMENT CLUSTER, SUPPLEMENTAL RESTRAINTS SYSTEMS
INTERIOR INTERIOR LIGHTS LIGHTS, SYSTEM EXTERIOR LIGHTS SYSTEMS
LOCK
LOCK OFF
LT GRN WIRE
MAIN BODY ECU
MAIN TRLY BODY ECU
OBD FUSE S/ROOF FUSE
ON OFF
P-DOOR D-DOOR UNLOCK UNLOCK RELAY RELAY
PANEL FUSE
PNK WIRE
POWER COMPUTER TOPS DATA LINES SYSTEM SYSTEM
POWER OUTLET SOCKET ASSEMBLY
POWER RELAY
POWER TOPS WIPER/WASHER SYSTEM SYSTEM
PWR OUTLET FUSE
RED WIRE
RELAY
S/HTR S/HTR FL FR FUSE FUSE
SEATS SYSTEM (LEFT KICK PANEL)
SHIFT INTERLOCK SYSTEM
SOUND MIRRORS SYSTEMS SYSTEM COOLING FANS SYSTEM
STARTING/ CHARGING SYSTEM
STARTING/CHARGING SYSTEM
TAIL FUSE
TAIL RELAY
TRANSMISSIONS, SHIFT INTERLOCK, WARNING, ELECTRONIC POWER STEERING SYSTEMS
VIO WIRE
WHT WIRE
WIP FR FUSE WASHER FR FUSE WASHER RR FUSE
WIP RR FUSE
YEL WIRE
Go to component -> Power distribution circuit (2 of 2) -> SOUND MIRRORS SYSTEMS SYSTEM COOLING FANS SYSTEM
