Scion tC II (2010-2013) security ind light Wiring diagrams
This page contains all the electrical diagrams for the component. security ind light, in which he is found in the car Scion tC II (2010-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram security ind light (1 of 2)
AGND
ANTENNA COIL
BLK WIRE
BLU WIRE
BRN WIRE
CLOCK ASSEMBLY
CODE
COM
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
INDS
INDW
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
LT GRN WIRE
NEO
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
SECURITY IND LIGHT
SWIL
TXCT
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER (LEFT REAR OF ENGINE COMPT)
YEL WIRE
Go to component -> Forced entry circuit, with smart key system (3 of 4) -> SECURITY IND LIGHT
Wiring diagram security ind light (2 of 2)
AGND
ANTENNA COIL
BLK WIRE
BLU WIRE
BRN WIRE
CLOCK ASSEMBLY
CODE
COM
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
INDS
INDW
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
LT GRN WIRE
NEO
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
SECURITY IND LIGHT
SWIL
TXCT
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER (LEFT REAR OF ENGINE COMPT)
YEL WIRE
Go to component -> Power door locks circuit, with smart key system (3 of 4) -> SECURITY IND LIGHT
