Scion tC II (2010-2013) right lssr front door w/ motor lock assembly Wiring diagrams
This page contains all the electrical diagrams for the component. right lssr front door w/ motor lock assembly, in which he is found in the car Scion tC II (2010-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right lssr front door w/ motor lock assembly (1 of 2)
+ECU
13 5 CANH CANL
5 4 3 2 1 PNK +B WIRE
BK/UP FUSE
BLK WIRE
BLU WIRE
BRN WIRE
BZR
COMPUTER DATA LINES SYSTEM
D DOOR UNLOCK RELAY
D/L FUSE
DETECTION
DP- DOOR LOCK RELAY
DRIVER'S SIDE DOOR COURTESY SWITCH
ENGINE COMPT)
ENGINE CONTROL MODULE (LEFT REAR OF ENGINE COMPT)
FRONT PASSENGER'S SIDE DOOR COURTESY SWITCH (RIGHT "B" PILLAR)
FUSE
GRN WIRE
GRY WIRE
HORN
HORNS SYSTEM
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE ECU-B FUSE OF ENGINE COMPT)
HOT IN ON OR ACC
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
INTERIOR LIGHTS SYSTEMS
KEY
LEFT UL FRONT DOOR W/ MOTOR LOCK ASSEMBLY
LOCK
LT GRN WIRE
MAIN BODY ECU
ORG/ WIRE
P- DOOR UNLOCK RELAY
PARK/NEUTRAL POSITION SWITCH (REAR OF TRANSMISSION)
PNK UL UNLOCK WIRE
PNK UL WIRE
PNK WIRE
POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY
PRG RDA GND
RED WIRE
RIGHT DOOR CONTROL SWITCH ASSEMBLY
RIGHT LSSR FRONT DOOR W/ MOTOR LOCK ASSEMBLY
UNLOCK
UNLOCK WARNING SWITCH ASSEMBLY (LEFT SIDE OF DASH)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER (LEFT REAR OF
YEL WIRE
Go to component -> Forced entry circuit, without smart key system -> RIGHT LSSR FRONT DOOR W/ MOTOR LOCK ASSEMBLY
