Scion tC II (2010-2013) pnk sblw te sg-3 gnd Wiring diagram
This page shows the only wiring diagram for the component.pnk sblw te sg-3 gnd, which is found in the car Scion tC II (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk sblw te sg-3 gnd (1 of 1)
A/C AMPLIFIER ASSEMBLY (LEFT CENTER OF DASH)
A/C LED
A/C PRESSURE SENSOR (RIGHT REAR OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BRN WIRE
CANH CANL SG-2
COMPRESSOR ASSEMBLY W/ PULLEY
COMPUTER DATA LINES SYSTEM
COOLER THERMISTOR 1
E F I ENGINE COOLANT TEMPERATURE SENSOR (FRONT OF ENGINE)
ECM (ENGINE CONTROL MODULE) (LEFT REAR OF ENGINE COMPT)
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
FLOQ
GRN WIRE
GRY WIRE
HEATER BLOWER MOTOR RELAY ASSEMBLY (RIGHT SIDE OF DASH)
HOT AT ALL TIMES
HOT IN ON OR START
HTR FUSE
HTR-IG FUSE
IG FUSE
INSTRUMENT PANEL J/B
LT GRN WIRE
ORG/ WIRE
PNK PNK WIRE
PNK SBLW TE SG-3 GND WIRE
PNK WIRE
PRE SOL+ IG+
QUEL
RED WIRE
SGFL
SOL +
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Manual a/c circuit (1 of 2) -> PNK SBLW TE SG-3 GND WIRE
