Scion tC II (2010-2013) pnk ig canl Wiring diagram
This page shows the only wiring diagram for the component.pnk ig canl, which is found in the car Scion tC II (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk ig canl (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 CANH
1 2 PIG PGND
2 6 3 4 5 ESS BAT CANL CANH
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
CAN CONTROLLER
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ECU-B FUSE (LEFT SIDE OF ENGINE COMPT)
ENGINE
ENGINE ROOM R/B
EPS ROOM J/B FUSE (LEFT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
MET FUSE
PNK IG CANL WIRE
POWER STEE- RING MOTOR
POWER STEERING ECU (LEFT SIDE OF DASH)
POWER STEERING IND
POWER STEERING MOTOR ASSEMBLY
POWER STEERING TORQUE SENSOR (TOP LEFT SIDE OF DASH)
RCOS
RED WIRE
RESOLVER SENSOR
RGND
RSIN
STEERING SENSOR (STEERING COLUMN)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Electronic power steering circuit -> PNK IG CANL WIRE
