Scion tC II (2010-2013) pnk bgnd Wiring diagram
This page shows the only wiring diagram for the component.pnk bgnd, which is found in the car Scion tC II (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk bgnd (1 of 1)
AIR BAG SENSOR ASSEMBLY (LOWER CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
BSW
BUCKLE SWITCH DRIVER'S SIDE FRONT SEAT INNER BELT (DRIVER'S SEAT BELT BUCKLE)
BUZZER
CAN CONTROLLER
CAN I/F
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DRIVER'S SIDE DOOR COURTESY SWITCH
ECU-B FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
GRY WIRE
HEAD
HEADLIGHT DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
IGN FUSE
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LIGHT CONTROL SWITCH
LT GRN WIRE
MAIN BODY ECU
MET FUSE
OCCUPANT CLASSIFICATION ECU (UNDER FRONT PASSENGER'S SEAT)
PNK BGND WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
SEAT BELT IND
TAIL
TAIL OFF
UNLOCK WARNING SWITCH
VIO WIRE
W/ DRL W/O DRL
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Key reminder & seat belt warning circuit -> PNK BGND WIRE
