Scion tC II (2010-2013) left rear speaker assembly Wiring diagram
This page shows the only wiring diagram for the component.left rear speaker assembly, which is found in the car Scion tC II (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear speaker assembly (1 of 1)
1 2 3 4 5 6 FR+ FL+ PNK WIRE
1 2 3 4 5 6 RR+ RL+ RR-
8 9 10 ANT AMP ILL+
AMP ROOM R/B FUSE (LEFT SIDE OF ENGINE COMPT)
ANTENNA
ANTENNA AMPLIFIER (CENTER OF DASH)
ARI ASGN ALI AGND AUXI
BLK WIRE
BLU WIRE
BRN WIRE
EAU
ENGINE
FR- FL- GND
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
ILL- RL-
INSTRUMENT CLUSTER SYSTEM
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT REAR SPEAKER ASSEMBLY
LT GRN WIRE
NCA WIRE
PNK WIRE
RAD 1 FUSE
RADIO RECEIVER ASSEMBLY
RED WIRE
RIGHT REAR SPEAKER ASSEMBLY
SEEK
SEEK- MODE
SPIRAL CABLE (ON STEERING COLUMN)
STEERING PAD SWITCH
STEREO JACK ADAPTER ASSEMBLY 1
SWG
VIO WIRE
VOL (-)
WHT WIRE
YEL WIRE
Go to component -> Radio circuit (1 of 2) -> LEFT REAR SPEAKER ASSEMBLY
