Scion tC II (2010-2013) headlight un lock dimmer warning switch switch assembly assembly Wiring diagram
This page shows the only wiring diagram for the component.headlight un lock dimmer warning switch switch assembly assembly, which is found in the car Scion tC II (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram headlight un lock dimmer warning switch switch assembly assembly (1 of 1)
BLOWER RESISTOR
BRN WIRE
CERTIFICATION ECU ASSEMBLY
CLOCK ASSEMBLY
COMBINATION METER ASSEMBLY
DLC 3
DRIVER'S DOOR
GRN WIRE
HEADLIGHT UN LOCK DIMMER WARNING SWITCH SWITCH ASSEMBLY ASSEMBLY
HEATER BLOWER MOTOR RELAY ASSEMBLY
ID CODE ENGINE BOX SWITCH
OCCUPANT DETECTION ECU
OF DASH)
PASSENGER'S DOOR
PNK WIRE
POWER OUTLET SOCKET ASSEMBLY
POWER SOURCE CONTROL ECU
RADIO RECEIVER ASSEMBLY
RIGHT DOOR CONTROL SWITCH ASSEMBLY
RIGHT FRONT DOOR WITH MOTOR LOCK ASSEMBLY
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
RIGHT OUTSIDE ELECTRICAL KEY ANTENNA
STEREO COMPONENT AMPLIFIER ASSEMBLY
TURN SIGNAL FLASHER ASSEMBLY
VIO WIRE
W/ SMART KEY SYSTEM W/O SMART KEY SYSTEM W/ MIRROR HEATER
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 3) -> HEADLIGHT UN LOCK DIMMER WARNING SWITCH SWITCH ASSEMBLY ASSEMBLY
