Scion tC II (2010-2013) 29 10 9 lin canl canh Wiring diagram
This page shows the only wiring diagram for the component.29 10 9 lin canl canh, which is found in the car Scion tC II (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 29 10 9 lin canl canh (1 of 1)
24 8 3 PNK SLR+ SLP WIRE
29 10 9 LIN CANL CANH
BLK WIRE
BLU WIRE
CERTIFICATION ECU (RIGHT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
GRN WIRE
HOT AT ALL TIMES ENGINE ROOM R/B STRG (LEFT SIDE OF LOCK ENGINE COMPT) FUSE
HOT IN ON OR START
IGN FUSE
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LIN
LT GRN WIRE
PNK IGE GND WIRE
PNK WIRE
POWER SOURCE CONTROL ECU (RIGHT SIDE OF DASH)
RED WIRE
STEERING LOCK ACTUATOR (LEFT SIDE OF DASH)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Steering column circuit -> 29 10 9 LIN CANL CANH
