Tire pressure monitoring circuit for Scion tC I facelift (2007-2010)

Tire pressure monitoring circuit

Get access

1 2 3 4 5 6 7 8 9 10 11 12 CLSW SPD TC TACH IND BLK WIRE BLU WIRE BRN WIRE BUZZER COMBINATION METER COMPUTER DATA LINES SYSTEM ECU-B FUSE ECU-IG FUSE ED (LEFT REAR OF ENGINE) ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FUSE GND SIL PNK WIRE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IH (BEHIND RIGHT SIDE OF DASH) INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) LT GRN WIRE ORG/ WIRE POWER CIRCUIT RDA GND RED WIRE RELAY ENERGIZED SPEEDOMETER TIRE PRESSURE IND TIRE PRESSURE WARNING ANTENNA, RECEIVER (IN RIGHT "C" PILLAR) TIRE PRESSURE WARNING ECU (BEHIND RIGHT SIDE OF DASH) TIRE PRESSURE WARNING RESET SWITCH VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
