Back door opener circuit for Scion tC I facelift (2007-2010)

Back door opener circuit

Get access

19 1 BDSU BACT 4 5 6 ALTB SIG ECUB BACK DOOR LOCK ASSEMBLY (REAR CENTER OF VEHICLE) BACK DOOR OPENER SWITCH (LEFT SIDE OF BACK DOOR) BK (AT REAR OF VEHICLE) BLK WIRE BLU WIRE BRN WIRE COMBINATION METER DOOR FUSE ECU-IG FUSE ED (LEFT REAR OF ENGINE) FUSE HOT AT ALL TIMES HOT AT ALL TIMES ENGINE ROOM R/B ECU B FUSE (LEFT SIDE OF ENGINE COMPT) HOT IN ON OR START IF (BEHIND LEFT SIDE OF DASH) IH (BEHIND RIGHT SIDE OF DASH) INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) INTEGRATION RELAY LT GRN WIRE ORG/ WIRE POWER CIRCUIT SKID CONTROL ECU W/ ACTUATOR (RIGHT FRONT OF ENGINE COMPT) SPEEDOMETER VIO WIRE WHT WIRE WHT/BLK WIRE
