Backup lamps circuit for Scion tC I facelift (2007-2010)
Backup lamps circuit
A/T
BACKUP LAMP
BACKUP LAMP SWITCH (ON RIGHT SIDE OF TRANSMISSION)
BLK WIRE
BRN WIRE
HOT IN ON OR START GAUGE FUSE
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
JUNCTION
JUNCTION CONNECTOR
LEFT REAR COMBINATION LAMP
M/T
PARK/NEUTRAL POSITION SWITCH (LEFT REAR OF TRANSMISSION)
PNK WIRE
RIGHT REAR COMBINATION LAMP BACKUP LAMP
WHT/BLK WIRE
