Scion tC I facelift (2007-2010) thwo imo imi tc pi 3 Wiring diagram
This page shows the only wiring diagram for the component.thwo imo imi tc pi 3, which is found in the car Scion tC I facelift (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram thwo imo imi tc pi 3 (1 of 1)
A/T
ACT
AIR CONDITIONING SYSTEM
ANTI-THEFT SYSTEM
BLK WIRE
BLU WIRE
BRN WIRE
C/OPN RELAY
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM
COOLING FANS SYSTEM
CRUISE CONTROL SYSTEM
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
EOM NSW PPMP
F/PS CANH CANL
FC VCPA
FUEL PUMP
FUEL SENDER FUEL SUCTION PUMP, GAUGE ASSEMBLY (IN FUEL TANK)
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IF (BEHIND LEFT SIDE OF DASH)
INSTRUMENT CLUSTER SYSTEM
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
LT GRN WIRE
M/T
ORG/ WIRE
PNK WIRE
RED WIRE
RR DEF I/UP FUSE
STOP FUSE
SUPPLEMENTAL RESTRAINTS SYSTEM
TAIL FUSE
THWO IMO IMI TC PI 3
VIO WIRE
VPMP MPMP +BM MREL IGSW
W/ ENGINE IMMOBILIZER SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.5l (1 of 6) -> THWO IMO IMI TC PI 3
