Scion tC I facelift (2007-2010) right rear combination lamp driver's side front seat inner belt Wiring diagram
This page shows the only wiring diagram for the component.right rear combination lamp driver's side front seat inner belt, which is found in the car Scion tC I facelift (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear combination lamp driver's side front seat inner belt (1 of 1)
AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) SHIELD
BACK DOOR CENTER OPENER STOP SWITCH LAMP
BI (BEHIND LEFT QUARTERPANEL)
BJ (BEHIND LEFT QUARTERPANEL)
BK (AT REAR OF VEHICLE)
BLK WIRE
BLU WIRE
BRN WIRE
CAMSHAFT POSITION SENSOR SHIELD
CANISTER PUMP MODULE
COMBINATION METER
CRANKSHAFT POSITION SENSOR SHIELD
DATA LINK CONNECTOR
DOOR CONTROL RECEIVER
EA (RIGHT FRONT OF ENGINE COMPARTMENT)
EB (RIGHT FRONT OF ENGINE COMPARTMENT)
EC (LEFT FRONT CORNER OF ENGINE COMPARTMENT)
ED (LEFT REAR OF ENGINE)
EE (REAR OF ENGINE)
EFI RELAY
ENGINE CONTROL MODULE
FAN 2 RELAY
GRY WIRE
HEATED OXYGEN SENSOR (BANK 1 SENSOR 2) SHIELD
IG (BEHIND LEFT SIDE OF DASH)
IG 2 RELAY
IGNITION
IGNITION IGNITION IGNITION COIL COIL COIL COIL
J/C
KNOCK CONTROL SENSOR (BANK 1) SHIELD
LEFT FRONT TURN SIGNAL LAMP
LEFT PARKING LAMP, SIDE MARKER LAMP
LEFT RADIO LICENSE RECEIVER PLATE LAMP ASSEMBLY
LEFT REAR COMBINATION LAMP
NCA WIRE
PNK WIRE
PRESSURE LEFT LOW SWITCH HEADLAMP
RADIATOR FAN MOTOR
RED WIRE
RIGHT BRAKE PARKING FLUID LAMP, LEVEL SIDE WARNING MARKER SWITCH LAMP
RIGHT FRONT SKID TURN CONTROL WINDSHIELD SIGNAL ECU W/ WIPER LAMP ACTUATOR MOTOR
RIGHT LICENSE PLATE LAMP
RIGHT LOW HEADLAMP
RIGHT REAR COMBINATION LAMP DRIVER'S SIDE FRONT SEAT INNER BELT
TIRE PRESSURE WARNING ECU
W/ ENGINE IMMOBILIZER SYSTEM
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (1 of 2) -> RIGHT REAR COMBINATION LAMP DRIVER'S SIDE FRONT SEAT INNER BELT
