Scion tC I facelift (2007-2010) horns system instrument cluster system Wiring diagram
This page shows the only wiring diagram for the component.horns system instrument cluster system, which is found in the car Scion tC I facelift (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram horns system instrument cluster system (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 BACT ACTD
BLK WIRE
BLU WIRE
BRN WIRE
DOOR FUSE
DOOR LOCKS SYSTEM
DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM
DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM INSTRUMENT CLUSTER SYSTEM
ECU-B FUSE
ECU-IG FUSE
EHW
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
EXTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM
FLASH RELAY
GRY WIRE
HAZ DCTY
HEAD BCTY BDSU LSWD DBKL PNK WIRE
HORN LSDI PRG RDA
HORNS SYSTEM INSTRUMENT CLUSTER SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
IF (BEHIND LEFT SIDE OF DASH)
IH (BEHIND RIGHT SIDE OF DASH)
INSTRUMENT CLUSTER SYSTEM DOOR LOCKS SYSTEM
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
INTEGRATION RELAY (BEHIND LEFT SIDE OF DASH)
KOF
LT GRN WIRE
ORG/ WIRE
POWER TOPS SYSTEM INTERIOR LIGHTS SYSTEM
POWER WINDOWS SYSTEM DOOR LOCKS SYSTEM
RED WIRE
T-LP RELAY
TAIL HRLY
TRLY PCTY
TRUNK, TAIL, FUEL DOORS SYSTEM DOOR LOCKS SYSTEM
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Body control modules circuit -> HORNS SYSTEM INSTRUMENT CLUSTER SYSTEM
