Scion tC I facelift (2007-2010) front passenger's side right outer door rear view lock assembly mirror Wiring diagram
This page shows the only wiring diagram for the component.front passenger's side right outer door rear view lock assembly mirror, which is found in the car Scion tC I facelift (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's side right outer door rear view lock assembly mirror (1 of 1)
A/T
AIR BAG SENSOR ASSEMBLY CENTER
BLOWER MOTOR CONTROL
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER ROOM LAMP
CIGARETTE LIGHTER
COMBINATION SWITCH
DATA LINK CONNECTOR
DOOR LOCK CONTROL SWITCH
DRIVER'S POWER SIDE DOOR WINDOW LOCK MASTER ASSEMBLY SWITCH
FLASH RELAY
FRONT PASSENGER'S SIDE POWER WINDOW SWITCH
FRONT PASSENGER'S SIDE RIGHT OUTER DOOR REAR VIEW LOCK ASSEMBLY MIRROR
FUEL SUCTION PUMP, GAUGE ASSEMBLY
HTR RELAY
IF (BEHIND LEFT SIDE OF DASH)
IG 1 RELAY
IH (BEHIND RIGHT SIDE OF DASH)
INSTRUMENT PANEL J/B
INTEGRATION RELAY
LEFT OUTER REAR VIEW MIRROR
MAP LAMP
NOISE FILTER
NOISE FILTER (DOME)
OUTER MIRROR TRANSPONDER SWITCH KEY ECU
POWER POINT J/C SOCKET RELAY
POWER POINT SOCKET
SHIFT LOCK CONTROL ECU
TIRE PRESSURE A/C WARNING CONTROL RESET ASSEMBLY SWITCH
UNLOCK WARNING SWITCH
W/ JAM PROTECTION
W/ JAM PROTECTION W/O JAM PROTECTION
W/ SLIDING ROOF
W/O JAM PROTECTION
WHT/BLK WIRE
Go to component -> Ground distribution circuit (2 of 2) -> FRONT PASSENGER'S SIDE RIGHT OUTER DOOR REAR VIEW LOCK ASSEMBLY MIRROR
