Scion tC I facelift (2007-2010) ecu-b fuse of engine compt) Wiring diagram
This page shows the only wiring diagram for the component.ecu-b fuse of engine compt), which is found in the car Scion tC I facelift (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ecu-b fuse of engine compt) (1 of 1)
1 2 3 4 5 AOF AOD REC FRS
4 3 2 1 VM +B SI GND
A/C CONTROL ASSEMBLY
A/C THERMISTOR 1 (BEHIND RIGHT SIDE OF DASH)
ACT
AMBIENT TEMPERATURE SENSOR (BEHIND GRILLE)
BLC PNK WIRE
BLK WIRE
BLOWER MOTOR (LOWER RIGHT SIDE OF DASH)
BLOWER MOTOR CONTROL (BEHIND CENTER OF DASH)
BLU WIRE
BRN WIRE
DAMPER SERVO MOTOR (AIR INLET) (BEHIND RIGHT SIDE OF DASH)
DAMPER SERVO MOTOR (AIR MIX) (BEHIND CENTER OF DASH)
DAMPER SERVO MOTOR (AIR VENT MODE) (BEHIND CENTER OF DASH)
ECU-B FUSE OF ENGINE COMPT)
ENGINE ROOM R/B (LEFT SIDE
FRHR GND TP
FUSE
GAUGE FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HTR FUSE
HTR RELAY
IF (BEHIND LEFT SIDE OF DASH)
IH (BEHIND RIGHT SIDE OF DASH)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK IG AMC AMH TAM TE WIRE
PNK WIRE
PRS
RED WIRE
SG-TPM SG-TP SG-TAM SG-TE TPM
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Manual a/c circuit (1 of 2) -> ECU-B FUSE OF ENGINE COMPT)
