Scion tC I facelift (2007-2010) door courtesy switch Wiring diagrams
This page contains all the electrical diagrams for the component. door courtesy switch, in which he is found in the car Scion tC I facelift (2007-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram door courtesy switch (1 of 2)
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
BRN WIRE
CLOSE
CLOSE/DOWN
COMBINATION METER
DOOR COURTESY SWITCH
DOOR FUSE
ECU-B FUSE
ECU-IG FUSE
ECUB
ED (LEFT REAR OF ENGINE)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FUSE
GND DCTY
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IF (BEHIND LEFT SIDE OF DASH)
IH (BEHIND RIGHT SIDE OF DASH)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
INTEGRATION RELAY
JUNCTION
JUNCTION CONNECTOR
KOF
LT GRN WIRE
MAP LAMP
OPEN/UP
ORG/ WIRE
PCTY
POWER CIRCUIT
PWS
S/ROOF FUSE
SIG
SLIDE ROOF CONTROL SWITCH
SLIDING ROOF CONTROL ECU (FRONT CENTER OF ROOF)
SPD PNK WIRE
SPEEDOMETER
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> DOOR COURTESY SWITCH
Wiring diagram door courtesy switch (2 of 2)
12 11 10 9 8 7 6 5 4 3 2 1 SGND PNK WIRE
20 19 18 17 16 15 14 13 IG VC
BLK WIRE
BLU WIRE
BRN WIRE
DOOR COURTESY SWITCH
DOOR FUSE
DOOR LOCKS SYSTEM
ECU-B FUSE
ECU-IG FUSE
ECUB PCTY DCTY
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
F/L DOOR FUSE
F/R DOOR FUSE
FRONT PASSENGER'S SIDE POWER WINDOW SWITCH
GAUGE FUSE
GND SGND
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IF (BEHIND LEFT SIDE OF DASH)
IH (BEHIND RIGHT SIDE OF DASH)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
INTEGRATION RELAY
JUNCTION CONNECTOR
KOF GND
KOP
LT GRN WIRE
ORG/ WIRE
PCT PLS
PCT PNK WIRE
PLS
PNK WIRE
POWER WINDOW MASTER SWITCH
RED WIRE
RIGHT FRONT POWER WINDOW REGULATOR MOTOR (IN RIGHT FRONT DOOR)
SIG
SSRB
VCC
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power windows circuit, with jam protection -> DOOR COURTESY SWITCH
