Scion tC I facelift (2007-2010) cds fuse Wiring diagrams
This page contains all the electrical diagrams for the component. cds fuse, in which he is found in the car Scion tC I facelift (2007-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram cds fuse (1 of 2)
A/C CONDENSER FAN MOTOR (FRONT OF ENGINE COMPT)
A/C CONTROL ASSEMBLY
BLK WIRE
BLU WIRE
BRN WIRE
CDS FUSE
DIODE (FAN) (BEHIND LEFT END OF DASH)
EC (LEFT FRONT CORNER OF ENGINE COMPT)
ECU-IG FUSE
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE)
FAN RELAY 1
FAN RELAY 2
FAN RELAY 3
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) RDI FUSE
HOT IN ON OR START
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
LT GRN WIRE
MGC
ORG/ WIRE
RED WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> CDS FUSE
Wiring diagram cds fuse (2 of 2)
A/C COMPRESSOR (RIGHT FRONT OF ENGINE COMPT)
A/C CONDENSER FAN MOTOR (FRONT OF ENGINE COMPT)
A/C FUSE
ACT
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
BRN WIRE
CDS FUSE
CIRCUIT
COMBINATION METER
DIODE (FAN) (BEHIND LEFT END OF DASH)
ECU-IG FUSE
ED (LEFT REAR OF ENGINE)
ENGINE COMPT) EC
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B 2 (LEFT SIDE OF ENGINE COMPT)
FAN RELAY 1
FAN RELAY 2
FAN RELAY 3
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B
HOT IN ON OR START
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
LT GRN WIRE
MGC RELAY
OF ENGINE COMPT)
ORG/ WIRE
PNK WIRE
POWER
PRESSURE SWITCH (LEFT FRONT OF ENGINE COMPT)
RADIATOR FAN MOTOR (LEFT FRONT
RDI FUSE (LEFT SIDE OF ENGINE COMPT)
RED WIRE
SPEEDOMETER
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Manual a/c circuit (2 of 2) -> CDS FUSE
