Scion tC I facelift (2007-2010) 18 26 20 19 27 21 vpa vcpa epa Wiring diagram
This page shows the only wiring diagram for the component.18 26 20 19 27 21 vpa vcpa epa, which is found in the car Scion tC I facelift (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 18 26 20 19 27 21 vpa vcpa epa (1 of 1)
+BM MREL BATT IGSW EOM
1 2 7 8 3 9 29 16 +B
18 26 20 19 27 21 VPA VCPA EPA
4 21 8 18 17 31 STP
4 5 8 3 M- M+
ACCELERATOR POSITION SENSOR (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
EC (LEFT FRONT CORNER OF ENGINE COMPT)
ED (LEFT REAR OF ENGINE)
EE (REAR OF ENGINE)
EFI FUSE
EFI RELAY
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
ETCS FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
JUNCTION
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
SPD PI TC CCS
THROTTLE BODY ASSEMBLY
TRANSMISSIONS SYSTEM
VC PNK WIRE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Cruise control circuit (1 of 2) -> 18 26 20 19 27 21 VPA VCPA EPA
