Front wiper/washer circuit for Scion tC I (2004-2007)

Front wiper/washer circuit

Get access

BLK WIRE BLU WIRE COMBINATION SWITCH FR WIP FUSE FR WSH FUSE FRONT WIPER SWITCH GRN WIRE HIGH OFF HOT IN ON OR START IH (BEHIND RIGHT SIDE OF DASH) IF (BEHIND LEFT SIDE OF DASH) INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) LOW/ MIST INT LOW/ MIST INT INT LOW/ MIST LT GRN WIRE OFF RED WIRE SOLID STATE VIO WIRE WASHER SWITCH WHT WIRE WHT/BLK WIRE WINDSHIELD WASHER MOTOR (ON RIGHT FRONT OF ENGINE COMPT) WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT) YEL WIRE
