Scion tC I (2004-2007) Immobilizer circuit

A/C CONTROL ASSEMBLY AGND BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CODE CTY DATA LINK CONNECTOR (DLC) 3 (LOWER LEFT END OF DASH) ECU-B FUSE EE (ON REAR OF ENGINE) EFII EFIO ENGINE CONTROL MODULE (BEHIND LOWER RIGHT SIDE OF DASH) ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IF (BEHIND LEFT SIDE OF DASH) IH (BEHIND RIGHT SIDE OF DASH) IMI IMO IND INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) JUNCTION CONNECTOR 1, 2 (LEFT END OF DASH) JUNCTION CONNECTOR 3 (LEFT SIDE OF DASH) JUNCTION CONNECTOR 4, 5 (LEFT KICK PANEL) JUNCTION CONNECTOR 6 (BEHIND LEFT SIDE OF DASH, JUNCTION CONNECTOR 9 (BEHIND RIGHT SIDE OF DASH) KEY COIL LT GRN WIRE ORG/ WIRE RED WIRE SECURITY INDICATOR LAMP TRANSPONDER TRANSPONDER KEY AMPLIFIER (ON STEERING COLUMN) TRANSPONDER KEY ECU (BEHIND LEFT SIDE OF DASH) TXCT UNLOCK WARNING SWITCH (LEFT SIDE OF DASH) VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
