Scion tC I (2004-2007) sil wfse tc ppmp vpa Wiring diagram
This page shows the only wiring diagram for the component.sil wfse tc ppmp vpa, which is found in the car Scion tC I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sil wfse tc ppmp vpa (1 of 1)
+BM
3 SPD
ACCELERATOR POSITION SENSOR (UNDER LEFT SIDE OF DASH)
ACMG
AIR CONDITIONING SYSTEM
ANTI-THEFT SYSTEM
BATT MPMP TACH
BLK WIRE
BLU WIRE
BRN WIRE
C/OPN RELAY
COMPUTER DATA LINES SYSTEM
DIODE (IDLE-UP) (AT LEFT KICK PANEL)
ENGINE CONTROL MODULE (BEHIND LOWER RIGHT SIDE OF DASH)
F/PS EOM
FUEL SUCTION PUMP, GAUGE ASSEMBLY (IN FUEL TANK)
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IF (BEHIND LEFT SIDE OF DASH)
IMO IMI
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
LT GRN WIRE
MREL IGSW FC
ORG/ WIRE
PNK A/CS WIRE
PNK ELS WIRE
PNK WIRE
RED WIRE
RR DEF I/UP FUSE
SIL WFSE TC PPMP VPA
STOP FUSE
SUPPLEMENTAL RESTRAINTS SYSTEM
TAIL FUSE
THWO
VCPA PNK WIRE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.4l (1 of 6) -> SIL WFSE TC PPMP VPA
