Scion tC I (2004-2007) pnk ig tpm tp tam Wiring diagram
This page shows the only wiring diagram for the component.pnk ig tpm tp tam, which is found in the car Scion tC I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk ig tpm tp tam (1 of 1)
A/C CONTROL ASSEMBLY
AIR MIX DAMPER SERVO MOTOR (BEHIND CENTER OF DASH)
AIR VENT MODE DAMPER SERVO MOTOR (BEHIND CENTER OF DASH)
AMBIENT TEMPERATURE SENSOR (BEHIND GRILLE)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
ED (ON LEFT REAR OF ENGINE)
ENGINE ROOM R/B (LEFT SIDE
FRHR BLC SPD
FUSE
FUSE ECU-B OF ENGINE COMPT)
FUSE GAUGE
FUSE HTR
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HTR RELAY
IF (BEHIND LEFT SIDE OF DASH)
IH (BEHIND RIGHT SIDE OF DASH)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR 1, 2 (LEFT END OF DASH)
JUNCTION CONNECTOR 4, 5
JUNCTION CONNECTOR 7 (BEHIND RIGHT SIDE OF DASH)
JUNCTION CONNECTOR 9 (BEHIND RIGHT SIDE OF DASH) (BEHIND RIGHT SIDE OF DASH) IH
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK IG TPM TP TAM WIRE
PNK WIRE
POWER CIRCUIT
RED WIRE
SG-TPM SG-TP SG-TAM
SPEEDOMETER
VIO WIRE
VM +B SI GND
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Manual a/c circuit (1 of 2) -> PNK IG TPM TP TAM WIRE
