Scion tC I (2004-2007) lh/ up rh/ down up down Wiring diagram
This page shows the only wiring diagram for the component.lh/ up rh/ down up down, which is found in the car Scion tC I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lh/ up rh/ down up down (1 of 1)
3 MV COM MH
5 MH
BLK WIRE
BLU WIRE
BRN WIRE
COM
HOT IN ACC OR ON
IF (BEHIND LEFT SIDE OF DASH)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) FUSE
J/C 4, 5 (LEFT KICK PANEL)
J/C 6 (BEHIND LEFT SIDE OF DASH)
LEFT REAR OUTER VIEW MIRROR
LH/ UP RH/ DOWN UP DOWN
LT GRN WIRE
M+ VL HR
OPERATION SWITCH
ORG/ WIRE
OUTER MIRROR SWITCH
RED WIRE
RIGHT REAR OUTER VIEW MIRROR
SELECT SWITCH
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> LH/ UP RH/ DOWN UP DOWN
