Scion tC I (2004-2007) 7 13 15 sil tc wfse Wiring diagram
This page shows the only wiring diagram for the component.7 13 15 sil tc wfse, which is found in the car Scion tC I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 7 13 15 sil tc wfse (1 of 1)
17 16 18 31 21 19 28 20 29 30 STA NSW VC
3 8 9 1 18 20 19 29 23 27 28 22 26 15 BATT MREL IGSW +B SIL TC WFSE
7 13 15 SIL TC WFSE
7 6 PNK WIRE
ACCELERATOR POSITION SENSOR (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
EC (LEFT FRONT CORNER OF ENGINE COMPT)
ED (ON LEFT REAR OF ENGINE)
EFI RELAY
ENGINE CONTROL MODULE (BEHIND LOWER RIGHT SIDE OF DASH)
ENGINE COOLANT TEMPERATURE SENSOR (ON REAR OF ENGINE)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) EFI FUSE
EPA VPA VCPA EOM
ETCS FUSE
FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) STOP FUSE
J/C 4, 5 (LEFT KICK PANEL)
J/C 7 (BEHIND RIGHT SIDE OF DASH)
J/C 8 (BEHIND RIGHT SIDE OF DASH)
LT GRN WIRE
M- M+
MASS AIR FLOW METER (ON LEFT SIDE OF ENGINE COMPT)
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
THA
THA EVG VG
THROTTLE BODY ASSEMBLY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> A/t circuit (1 of 2) -> 7 13 15 SIL TC WFSE
