Scion iM I (2015-2016) vsc off ind Wiring diagrams
This page contains all the electrical diagrams for the component. vsc off ind, in which he is found in the car Scion iM I (2015-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram vsc off ind (1 of 2)
ABS 1 FUSE
ABS 3 FUSE
ABS IND.
AIR BAG SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL WARNING SWITCH (BRAKE MASTER CYLINDER RESERVOIR SUB-ASSEMBLY)
BRAKE IND
BRN WIRE
CAN CONTROLLER
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
ECU-B 1 FUSE
ENGINE ROOM R/B ASSEMBLY
GRN WIRE
HOT AT ALL TIMES
LED DRIVER
LT BLU WIRE
LT GRN WIRE
PNK WIRE
RED WIRE
RIGHT REAR SPEED SENSOR
SLIP IND
STEERING SENSOR (SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY)
VIO WIRE
VSC OFF IND
WHT WIRE
WHT/BLK WIRE
YAW RATE SENSOR
YEL WIRE
Go to component -> Anti-lock brakes circuit (2 of 2) -> VSC OFF IND
