Scion iM I (2015-2016) quick heater assembly Wiring diagram
This page shows the only wiring diagram for the component.quick heater assembly, which is found in the car Scion iM I (2015-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram quick heater assembly (1 of 1)
AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) SHIELD
BACK DOOR LOCK ASSEMBLY
BACK DOOR OPENER SWITCH ASSEMBLY
BRN WIRE
CANISTER PUMP MODULE
CENTER STOP LIGHT ASSEMBLY
COMPRESSOR W/ PULLEY ASSEMBLY
CRANK POSITION SENSOR SHIELD
CRUISE CONTROL MAIN SWITCH
FUEL PUMP CONTROL ECU ASSEMBLY
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
KNOCK CONTROL SENSOR SHIELD
LEFT "C" PILLAR)
LEFT REAR COMBINATION LIGHT ASSEMBLY
LEFT REAR LIGHT ASSEMBLY
OCCUPANT DETECTION ECU
POWER STEERING ECU ASSEMBLY
QUICK HEATER ASSEMBLY
REAR WINDOW DEFOGGER
REAR WIPER MOTOR ASSEMBLY
RIGHT END OF DASH)
RIGHT REAR LIGHT ASSEMBLY
SHIELD
SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY
TOP OF ENGINE)
WHT/BLK WIRE
Go to component -> Ground distribution circuit (2 of 4) -> QUICK HEATER ASSEMBLY
