Scion iM I (2015-2016) power steering torque sensor Wiring diagram
This page shows the only wiring diagram for the component.power steering torque sensor, which is found in the car Scion iM I (2015-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power steering torque sensor (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
CAN CONTROLLER
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ECU-B 1 FUSE
ECU-B 3 FUSE
ECU-IG 5 FUSE
ELECTRIC POWER STEERING COLUMN SUB-ASSEMBLY
ENGINE ROOM R/B ASSEMBLY
EPS FUSE
EPS RELAY
EPS-IG 1 FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IG+ PNK WIRE
INSTRUMENT PANEL J/B ASSEMBLY
LED DRIVER
LT BLU WIRE
LT GRN WIRE
METER FUSE
PNK WIRE
POWER STEERING ECU ASSEMBLY
POWER STEERING IND
POWER STEERING MOTOR
POWER STEERING TORQUE SENSOR
RED WIRE
RELAY ENERGIZED
RLY
STEERING SENSOR (SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Electronic power steering circuit -> POWER STEERING TORQUE SENSOR
