Scion iM I (2015-2016) engine controls, anti-lock brakes, transmissions, exterior lights systems Wiring diagram
This page shows the only wiring diagram for the component.engine controls, anti-lock brakes, transmissions, exterior lights systems, which is found in the car Scion iM I (2015-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine controls, anti-lock brakes, transmissions, exterior lights systems (1 of 1)
ACC FUSE
ACC RELAY
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
CIG FUSE
COOLING FANS SYSTEM
DEFOGGER SYSTEM
ECU- IG 1 FUSE
ECU-IG 2 FUSE
ECU-IG 3 FUSE
ECU-IG 4 FUSE
ECU-IG 5 FUSE
ELECTRONIC POWER STEERING SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS, ANTI-LOCK BRAKES, TRANSMISSIONS, EXTERIOR LIGHTS SYSTEMS
ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
FD (RIGHT SIDE OF DASH)
FROM ENGINE ROOM R/B ASSEMBLY (DIAGRAM 1 OF 3)
FROM IGNITION/ STARTER SWITCH ASSEMBLY (DIAGRAM 2 OF 3)
FROM INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 2 OF 3)
FROM POWER RELAY (DIAGRAM 2 OF 3)
GRN WIRE
GRY WIRE
HTR-IG FUSE
INSTRUMENT CLUSTER SYSTEM
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
MIRRORS SYSTEM
PANEL FUSE
PNK WIRE
POWER OUTLET SOCKET ASSEMBLY 1
SFT LOCK- ACC FUSE
SHIFT INTERLOCK SYSTEM
SHIFT INTERLOCK, TRANSMISSIONS SYSTEMS
SOUND SYSTEMS
STARTING/ CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TAIL FUSE
TAIL RELAY
TRANSMISSIONS SYSTEM
USED)
VIO WIRE
WARNING SYSTEMS
WASHER FUSE
WHT WIRE
WHT/BLK WIRE
WIPER 1 FUSE
WIPER RR FUSE
WIPER/ WASHER SYSTEM
Go to component -> Power distribution circuit (3 of 3) -> ENGINE CONTROLS, ANTI-LOCK BRAKES, TRANSMISSIONS, EXTERIOR LIGHTS SYSTEMS
