Scion iM I (2015-2016) dome cut relay Wiring diagram
This page shows the only wiring diagram for the component.dome cut relay, which is found in the car Scion iM I (2015-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dome cut relay (1 of 1)
ACC FUSE
BACK DOOR LOCK ASSEMBLY
BLU WIRE
COMPUTER DATA LINES SYSTEM
COURTESY SWITCH
CTY
DOME CUT RELAY
DOME FUSE
ECU-B 1 FUSE
ECU-IG 4 FUSE
ENGINE ROOM R/B ASSEMBLY
GRN WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
INSTRUMENT PANEL J/B ASSEMBLY
LCTY
LEFT "C" PILLAR)
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
LEFT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY
LEFT VANITY LIGHT ASSEMBLY
LT BLU WIRE
LT GRN WIRE
LUGGAGE COMPARTMENT LIGHT ASSEMBLY
MAIN BODY ECU
MAP LIGHT ASSEMBLY
PNK WIRE
R/B 4
RCTY
RED WIRE
RELAY ENERGIZED
RIGHT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
RIGHT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY
RIGHT VANITY LIGHT ASSEMBLY
ROOM LIGHT ASSEMBLY 1
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Courtesy lamps circuit -> DOME CUT RELAY
