Rear sonar circuit for Scion iA I (2015-2016)
Rear sonar circuit
BLK WIRE
BLU WIRE
BODY ECU (LEFT END OF DASH)
BRN WIRE
CLEARANCE WARNING BUZZER 1
CLEARANCE WARNING ECU ASSEMBLY
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
LEFT REAR CENTER ULTRASONIC SENSOR 1
LEFT REAR ULTRASONIC SENSOR 1
LT GRN WIRE
METER 1 FUSE
MICROCOMPUTER
ORG/ WIRE
PNK WIRE
RADIO RECEIVER ASSEMBLY (W/O MULTI DISPLAY)
RED WIRE
RELAY & FUSE BLOCK
RIGHT END OF DASH)
RIGHT REAR CENTER ULTRASONIC SENSOR 1
RIGHT REAR ULTRASONIC SENSOR 1
STEREO COMPONENT AMPLIFIER ASSEMBLY
TRANSMISSION CONTROL MODULE (AUTOMATIC TRANSAXLE ASSEMBLY)
VIO WIRE
WARNING/ INDICATOR LIGHTS
WHT WIRE
YEL WIRE
