Scion iA I (2015-2016) right front power window regulator motor assembly Wiring diagram
This page shows the only wiring diagram for the component.right front power window regulator motor assembly, which is found in the car Scion iA I (2015-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front power window regulator motor assembly (1 of 1)
AUTO
BLK WIRE
BLU WIRE
BRN WIRE
CLOSE
CLOSE RELAY
DOOR LOCKS SYSTEM
GRN WIRE
GRY WIRE
HALL EFFECT SWITCH 1
HALL EFFECT SWITCH 2
LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY
LEFT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
LOCK UNLOCK
LT BLU WIRE
LT GRN WIRE
MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
OPEN RELAY
P/W CM
PNK WIRE
POWER-CUT SWITCH
RED WIRE
RIGHT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power windows circuit (1 of 2) -> RIGHT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY
