Scion iA I (2015-2016) power steering ecu Wiring diagrams
This page contains all the electrical diagrams for the component. power steering ecu, in which he is found in the car Scion iA I (2015-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
power steering ecu wiring diagram (1 of 4)
AIR BAG SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
BODY ECU (LEFT END OF DASH)
BRN WIRE
COMBINATION METER ASSEMBLY
D LOCK FUSE
DATA LINK CONNECTOR 3
DOOR LOCKS, ANTI-THEFT SYSTEMS
EXTERIOR LIGHTS, NAVIGATION SYSTEMS
FUSE BLOCK
GRN WIRE
GRY WIRE
H/L LH FUSE
H/L RH FUSE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
NAVIGATION RECEIVER (W/ MULTI-DISPLAY)
ORG/ WIRE
PNK WIRE
POWER STEERING ECU
R WIPER FUSE
RED WIRE
RELAY & FUSE BLOCK
SUPPLEMENTAL RESTRAINTS SYSTEM
TAIL FUSE
VIO WIRE
WHT WIRE
WIPER/WASHER SYSTEM
Go to component -> Body control modules circuit (2 of 4) -> POWER STEERING ECU
power steering ecu wiring diagram (2 of 4)
A/C AMPLIFIER (CENTER OF DASH)
AIR BAG SENSOR ASSEMBLY
AUTOMATIC A/C
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY
COMBINATION METER ASSEMBLY
DATA LINK CONNECTOR 3
DISC PLAYER
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
MANUAL A/C
POWER STEERING ECU
RED WIRE
RELAY & FUSE BLOCK
TRANSMISSION CONTROL MODULE (AUTOMATIC TRANSAXLE ASSEMBLY)
VIO WIRE
W/O DUAL-STAGE SRS
W/O HEADLIGHT BEAM LEVEL CONTROL
WHT WIRE
Go to component -> Computer data lines circuit (1 of 2) -> POWER STEERING ECU
power steering ecu wiring diagram (3 of 4)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DD (LEFT SIDE OF DASH)
EPAS FUSE
GRN WIRE
HOT AT ALL TIMES
LCD
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU 2
MAIN FUSE
METER 1 FUSE
MICRO COMPUTER
POWER STEERING ECU
RED WIRE
RELAY & FUSE BLOCK
RELAY ENERGIZED
SRS 1 FUSE
STEERING SENSOR (SPIRAL CABLE SUB-ASSEMBLY)
VIO WIRE
WARNING/ INDICATOR LIGHTS
Go to component -> Electronic power steering circuit -> POWER STEERING ECU
power steering ecu wiring diagram (4 of 4)
A/C AMPLIFIER
A/C CONTROL ASSEMBLY
A/T
AUTOMATIC A/C
AUTOMATIC A/C MANUAL A/C
BACKUP LIGHT SWITCH ASSEMBLY
BLK WIRE
BLUETOOTH UNIT
BLUETOOTH UNIT (SHIELD)
CA (LEFT REAR OF ENGINE)
CLEARANCE WARNING ECU ASSEMBLY
DA (RIGHT SIDE OF DASH)
DC (RIGHT SIDE OF DASH)
DD (LEFT SIDE OF DASH)
DE (W/O MULTI-DISPLAY) (LEFT CENTER OF DASH)
DISC PLAYER
HAZARD WARNING SIGNAL SWITCH ASSEMBLY
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
M/T
NEUTRAL SWITCH
POWER OUTLET SOCKET ASSEMBLY 1
POWER STEERING ECU
RADIO RECEIVER ASSEMBLY
RADIO RECEIVER ASSEMBLY (SHIELD)
REAR WINDOW DEFOGGER (BACK WINDOW GLASS)
SHIELD
SHIFT LOCK CONTROL UNIT ASSEMBLY
STEREO JACK ADAPTER ASSEMBLY 1
STEREO JACK ADAPTER ASSEMBLY 1 SHIELD
TELEPHONE MICROPHONE ASSEMBLY (SHIELD)
W/ BLUETOOTH SYSTEM
ZA (LEFT REAR DOOR SILL)
Go to component -> Ground distribution circuit (2 of 4) -> POWER STEERING ECU
