Scion iA I (2015-2016) pcs off switch Wiring diagram
This page shows the only wiring diagram for the component.pcs off switch, which is found in the car Scion iA I (2015-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pcs off switch (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
INDICATOR LIGHTS
LCD
LEFT FRONT SPEED SENSOR
LEFT REAR SPEED SENSOR
LT GRN WIRE
MICROCOMPUTER
PARKING BRAKE SWITCH ASSEMBLY
PCS OFF SWITCH
RED WIRE
RIGHT FRONT SPEED SENSOR
RIGHT REAR SPEED SENSOR
TPMS SET SWITCH
VIO WIRE
VSC OFF SWITCH
VSC SWITCH
WARNING
WHT WIRE
Go to component -> Anti-lock brakes circuit (2 of 2) -> PCS OFF SWITCH
