Scion iA I (2015-2016) all times hot at Wiring diagram
This page shows the only wiring diagram for the component.all times hot at, which is found in the car Scion iA I (2015-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram all times hot at (1 of 1)
ALL TIMES HOT AT
BLK WIRE
BODY ECU
BRN WIRE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
INTERIOR FUSE
LCD
LEVEL WARNING SWITCH ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
MAIN BODY ECU 2
MICROCOMPUTER
ORG/ WIRE
PNK WIRE
R WIPER FUSE
RAIN SENSOR
RED WIRE
RELAY & FUSE BLOCK
RELAY ENERGIZED
VIO WIRE
WARNING/ INDICATOR LIGHTS
WASHER FLUID RESERVOIR)
WASHER FUSE
WHT WIRE
WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY
WINDSHIELD WIPER MOTOR ASSEMBLY
WINDSHIELD WIPER SWITCH
WIPER HI RELAY
WIPER INT RELAY
Go to component -> Wiper/washer circuit -> ALL TIMES HOT AT
