Scion FR-S I (2012-2016) Immobilizer circuit

19 18 CANH CANL AGND ASSEMBLY (IGNITION SWITCH LOCK CYLINDER ASSEMBLY) (ON STEERING COLUMN) BLK WIRE BLK/PNK WIRE BLK/YEL WIRE BLU/RED WIRE BMPX BRN WIRE BRN/WHT WIRE CAN DRIVER CODE COMBINATION METER ASSEMBLY COMPT) COMPUTER DATA LINES SYSTEM ECM (ENGINE CONTROL MODULE) (RIGHT END OF DASH) ECU-ACC FUSE ECU-B FUSE ENGINE ROOM FUSE GAUGE FUSE GRN WIRE GRN/RED WIRE GRY WIRE HAZ FUSE HOT AT ALL TIMES HOT W/ HOT W/ ACC 1 RELAY ENERGIZED IGNITION KEY CODE CYLINDER LIGHT IND ILL+ ILL IMO IND INSTRUMENT PANEL JUNCTION BLOCK (LEFT END OF DASH) KSWB LT BLU WIRE LT GRN WIRE MAIN BODY ECU MPX-B FUSE ORG/ WIRE PNK WIRE POWER CIRCUIT POWER DISTRIBUTION SYSTEM R/B, J/B (RIGHT FRONT OF ENGINE RED WIRE RED/WHT WIRE RELAY ENERGIZED SECURITY IND TRANSPONDER KEY AMPLIFIER (ON STEERING COLUMN) TRANSPONDER KEY COIL TRANSPONDER KEY ECU (IF EQUIPPED) (CENTER OF DASH) TXCT UART UN-LOCK WARNING SWITCH VIO WIRE W/O TIRE PRESSURE WARNING SYSTEM WHT WIRE WHT/GRN WIRE YEL WIRE
