Scion FR-S I (2012-2016) throttle body w/ motor assembly shield Wiring diagram
This page shows the only wiring diagram for the component.throttle body w/ motor assembly shield, which is found in the car Scion FR-S I (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram throttle body w/ motor assembly shield (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CENTER REAR OF LUGGAGE COMPT)
CENTER STOP LIGHT ASSEMBLY
CRANKSHAFT POSITION SENSOR SHIELD
FUEL INJECTOR ASSEMBLY (FOR DIRECT INJECTION 1) SHIELD
FUEL INJECTOR ASSEMBLY (FOR DIRECT INJECTION 2) SHIELD
FUEL INJECTOR ASSEMBLY (FOR DIRECT INJECTION 3) SHIELD
FUEL INJECTOR ASSEMBLY (FOR DIRECT INJECTION 4) SHIELD
FUEL PUMP CONTROL ECU ASSEMBLY
HEATED OXYGEN SENSOR (BANK 1 SENSOR 2) SHIELD
IGNITION COIL
INJ RELAY SHIELD
INTAKE MASS AIR FLOW METER SUB-ASSEMBLY SHIELD
KNOCK CONTROL SENSOR (BANK 1) SHIELD
KNOCK CONTROL SENSOR (BANK 2) SHIELD
LEFT FRONT SEAT INNER BELT ASSEMBLY
LEFT LICENSE PLATE LIGHT LENS
LEFT REAR COMBINATION LIGHT LENS, BODY
LEFT SEAT HEATER
POWER STEERING ECU
RADIO RECEIVER ASSEMBLY
REAR WINDOW DEFOGGER (BACK WINDOW GLASS)
RED WIRE
RIGHT REAR BACKUP COMBINATION LIGHT LIGHT LENS, LENS, BODY BODY
RIGHT SEAT HEATER
SPILL CONTROL VALVE (FUEL PUMP ASSEMBLY) SHIELD
STEREO COMPONENT AMPLIFIER ASSEMBLY
THROTTLE BODY W/ MOTOR ASSEMBLY SHIELD
TRUNK LOCK ASSEMBLY
TRUNK OPENER SWITCH ASSEMBLY
TRUNK RIGHT OPENING LICENSE CANCEL PLATE SWITCH LIGHT ASSEMBLY LENS
W/ TIRE PRESSURE WARNING SYSTEM
W/O TIRE PRESSURE WARNING SYSTEM
WHT WIRE
WIDE RANGE AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) SHIELD
Go to component -> Ground distribution circuit (3 of 3) -> THROTTLE BODY W/ MOTOR ASSEMBLY SHIELD
