Scion FR-S I (2012-2016) right seat left seat heater heater switch switch Wiring diagram
This page shows the only wiring diagram for the component.right seat left seat heater heater switch switch, which is found in the car Scion FR-S I (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right seat left seat heater heater switch switch (1 of 1)
A DR LOCK/ P DR D DR SET UNLOCK UNLOCK RELAY RELAY RELAY
A/C AMPLIFIER ASSEMBLY
AIR BAG CONTROL MODULE
AIR BAG ECU ASSEMBLY
BK/DR RELAY RELAY
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CERTIFICATION ECU
CLOCK ASSEMBLY
COMBINATION METER ASSEMBLY
HEADLIGHT DIMMER SWITCH ASSEMBLY
HEATER CONTROL SUB ASSEMBLY 3
HEATER CONTROL SUB-ASSEMBLY
JUNCTION CONNECTOR
LEFT DOOR LOCK W/ MOTOR ASSEMBLY
MAIN BODY ECU
OUTER MIRROR SWITCH ASSEMBLY
PADDLE SHIFT SWITCH
POWER OUTLET SOCKET ASSEMBLY 2
POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY
POWER WINDOW REGULATOR SWITCH ASSEMBLY
RADIO RECEIVER ASSEMBLY
RELAY RELAY
RELAY RELAY RELAY
RIGHT DOOR LOCK W/ MOTOR ASSEMBLY
RIGHT SEAT LEFT SEAT HEATER HEATER SWITCH SWITCH
ROLL CONNECTOR (A/T)
STEERING LOCK ACTUATOR ASSEMBLY
STEERING SENSOR
TRIP SWITCH
TRUNK OPENING SWITCH ASSEMBLY
W/O SMART ENTRY, START SYSTEM
WINDSHIELD TURN SIGNAL WIPER FLASHER SWITCH ASSEMBLY ASSEMBLY
YEL BLK/ WIRE
Go to component -> Ground distribution circuit (2 of 3) -> RIGHT SEAT LEFT SEAT HEATER HEATER SWITCH SWITCH
