Scion FR-S I (2012-2016) opener trunk opener switch assembly Wiring diagrams
This page contains all the electrical diagrams for the component. opener trunk opener switch assembly, in which he is found in the car Scion FR-S I (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram opener trunk opener switch assembly (1 of 2)
3 4 5 6 PNK WIRE
ACCD
ACCR
AGND
ANTENNA COIL
BLK WIRE
BLU WIRE
BRN WIRE
CANH CANL SWIL LIN
CENTER REAR OF LUGGAGE COMPT)
CERTIFICATION ECU (RIGHT END OF DASH)
CLGB
CODE
COMPUTER DATA LINES SYSTEM
ENGINE SWITCH
GAUGE FUSE
GRN WIRE
GRN/YEL WIRE
GRY WIRE
INSTRUMENT PANEL JUNCTION BLOCK (LEFT END OF DASH)
J/C
LIN
LT BLU WIRE
LT GRN WIRE
OPENER TRUNK OPENER SWITCH ASSEMBLY
ORG/ WIRE
PNK RDA WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RCO
RED WIRE
RELAY ENERGIZED
RSSI
SHIFT INTERLOCK SYSTEM
SL/R
SLP
SLP SPD PNK PNK WIRE
STEERING LOCK ACTUATOR (ON STEERING COLUMN)
SWIL
TXCT
VIO WIRE
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Forced entry circuit (1 of 5) -> OPENER TRUNK OPENER SWITCH ASSEMBLY
Wiring diagram opener trunk opener switch assembly (2 of 2)
3 4 5 6 PNK WIRE
ACCD
ACCR
AGND
ANTENNA COIL
BLK WIRE
BLU WIRE
BRN WIRE
CANH CANL SWIL LIN
CENTER REAR OF LUGGAGE COMPT)
CERTIFICATION ECU (RIGHT END OF DASH)
CLGB
CODE
COMPUTER DATA LINES SYSTEM
ENGINE SWITCH
GAUGE FUSE
GRN WIRE
GRN/YEL WIRE
GRY WIRE
INSTRUMENT PANEL JUNCTION BLOCK (LEFT END OF DASH)
J/C
LIN
LT BLU WIRE
LT GRN WIRE
OPENER TRUNK OPENER SWITCH ASSEMBLY
ORG/ WIRE
PNK RDA WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RCO
RED WIRE
RELAY ENERGIZED
RSSI
SHIFT INTERLOCK SYSTEM
SL/R
SLP
SLP SPD PNK PNK WIRE
STEERING LOCK ACTUATOR (ON STEERING COLUMN)
SWIL
TXCT
VIO WIRE
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Power door locks circuit, with smart entry & start system (1 of 5) -> OPENER TRUNK OPENER SWITCH ASSEMBLY
