Scion FR-S I (2012-2016) on 1 3 gnd door sw off pnk Wiring diagram
This page shows the only wiring diagram for the component.on 1 3 gnd door sw off pnk, which is found in the car Scion FR-S I (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram on 1 3 gnd door sw off pnk (1 of 1)
+ECU
BLK WIRE
BLK/YEL WIRE
BLU WIRE
CLOCK ASSEMBLY
COMPUTER DATA LINES SYSTEM
DOME FUSE
DOOR
ECU-ACC FUSE
ECU-B FUSE
ENGINE ROOM R/B, J/B (RIGHT FRONT OF ENGINE COMPT)
FDCY
FLCL FRCL
FPCY
FUSE
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACC 1 RELAY ENERGIZED
J/C
LEFT FRONT COURTESY LIGHT ASSEMBLY (IF EQUIPPED)
LEFT FRONT DOOR COURTESY LIGHT SWITCH (IN LEFT FRONT "B" PILLAR)
LEFT VANITY LIGHT ASSEMBLY (IF EQUIPPED)
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU INSTRUMENT PANEL J/B (LEFT END OF DASH)
MAP LIGHT ASSEMBLY
ON 1 3 GND DOOR SW OFF PNK WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT FRONT COURTESY LIGHT ASSEMBLY (IF EQUIPPED)
RIGHT FRONT DOOR COURTESY LIGHT SWITCH (IN RIGHT FRONT "B" PILLAR)
RIGHT VANITY LIGHT ASSEMBLY (IF EQUIPPED)
TRUNK LIGHT ASSEMBLY 1 (IF EQUIPPED)
TRUNK LOCK ASSEMBLY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL/BLK WIRE
Go to component -> Courtesy lamps circuit -> ON 1 3 GND DOOR SW OFF PNK WIRE
